Engineered to increase vehicle visibility, the Tracers now connect over the WeCanX® network and offer more customization than ever before. Though similar in design to its predecessor, the new Tracer uses enhanced optics to provide dynamic lighting output and control. Lightheads are daisy-chained together in lengths of one to six modules, with each module containing four individually controlled segments for contiguous lighting display and expanded configuration to meet a variety of needs. Upgraded lens design and IP67 rating for dust and water resistance improve performance and durability. The durable clamshell design allows for easy reconfiguration and serviceability. Each Module are 12.5 inches each.

Note: All Mounting Brackets sold separately. Please use the below if using Universal L Mounting Brackets
1 Module Tracer Requires 2 L Brackets or a Vehicle Specific Mount Sold Above
2 Module Tracer Requires 3 L Brackets or a Vehicle Specific Mount Sold Above
3 Module Tracer Requires 4 L Brackets or a Vehicle Specific Mount Sold Above
4 Module Tracer Requires 5 L Brackets or a Vehicle Specific Mount Sold Above
5 Module Tracer Requires 6 L Brackets or a Vehicle Specific Mount Sold Above
6 Module Tracer Requires 7 L Brackets or a Vehicle Specific Mount Sold Above

FEATURES

• Vehicle-to-Vehicle Synchronization
• SOLO™ (single color)
• DUO™ (two color interleaved), or TRIO™ (three color interleaved) modules available.
• Lightheads are daisy-chained together in lengths from 1 to 6 modules using the provided extrusion
• 30 Scan-Lock™ flash patterns
• SOLO models include Traffic-Advisor™ in 4-6 lamp versions
• Cruise light control includes seven adjustable intensity levels
• Custom light configuration choices are achieved via the mode control wire
• Hard-coated lenses resist environmental damage from sand, sun, salt, and road chemicals
• Easily serviceable clamshell design
• Mounts easily via slide bolt with vehicle specific brackets or universal “L" brackets
• Includes 15' cable with fully encapsulated in-line lamp driver
• Mounting Brackets Purchased Separately
• Whelen tracers are Special / Custom built to order items, which may require a lead time of minimum 4 weeks.
• Please contact us if there are any questions regarding lead times PRIOR to placing an order, as these cannot be cancelled.
• Five year warranty
• Tracers are sold individually - ONE Control point will control up to Two (2) Tracery Light Arrays
• SPECIFICATIONS

• SAE Class 1 Certified
• IP67 rated for dust and water resistance
• 12 VDC
• 0.5 amps peak per module
• Size, single module: .75" (19mm) H x 1.75" (44.45mm) D x 12.5" (317.5mm) L
